20. Mount:
¡¤Valve cover ¢Ù(mount o-ring in the sealing
groove of throttle cover first)
¡¤Valve cover¢Ú(mount o-ring in the sealing
groove of throttle cover first)
¡¤Spark plug ¢Û
Caution
Check the o-ring, if it is deformed or damaged,
replace it.
21. Mount:
¡¤Sprocket chamber cover ¢Ù(mount o-ring in
the sealing groove of
sprocket chamber cover
first).
Caution
Check the o-ring, if it is deformed or damaged,
replace it.
22. Mount:
¡¤O-ring ¢Ù
¡¤
Carburetor seat¢Ú
¡¤
Washer ¢Û
¡¤
Carburetor ¢Ü (mount o-ring in sealing
groove first)
Caution
Check all o-ring . If it is damaged, replace it.
23. Mount:
¡¤Carburetor seat and carburetor (on cylin-
der cover)
¡¤Wire clamp ¢Ù
Caution
The carburetor seat and the o-ring in the seal-
ing groove of cylinder cover connecting sur-
face can’ t be forgotten to mount.
¢Ù
¢Ú
¢Û
¢Ü
¢Ù
