2.Check if the rear wheel fork assy is crack
bend and damaged, if any, replace it.
Check if the rear wheel bush is crack, bend
and damaged. If there is one of these prob-
lems replace it.
3.Check the gear case lower cap, if there is
one of crack bend and damaging problems, re-
place this part.
4.Check the rear arm joint bolt ¢Ù and rear
arm joint bolt ¢Úand bush ¢Û.If one of these
parts is worn or damaged, replace it.
5.Check the bearing 360203 ¢Ù of rear wheel
fork assy, if ther is free clearance during the
bearing matches with the rear wheel fork, or
uneven swirl, replace the bearing.Check the
oil sealing¢Ú ,if it is worn or damaged, replace
it.
Replacing steps of bearing 30203and oil seal-
ing .
a:Clean the bearing round
b:Take off the oil sealing ¢Ùwith flat
screwdriver.
Put a wooden block ¢Úat the outer side in or-
der to protect the outer side.
Caution
- 110 -
