2)Measure
.Installing pressure of valve spring
If unqualified, replace the inner and outer
spring totally.
6.Seal check of valve
1)Installation of valve
Lubricate
.Valve rod part
.Valve rod oil seal
Install
.Valve spring seat(Lower part)
.Oil seal of valve rod
.Valve
.Inner spring of valve
.Outer spring of valve
.Spring cover of valve
.Locking clip of valve
Installing pressure of valve spring
Inner spring(intake/
exhaust)
When it is 30.5mm(1.2 in),the
pressure8.4~10.2kg(18.5~22.
5pods)
Outerspring(intake/
exhaust)
When it is 32.0mm(1.26 in),the
pressure16.6~20.4kg(36.6~45.
0pods)
- 161 -
Apply molybednum
disulfide oil
Apply molybdenum
disulfide oil
Installation
length
