11) Installment
¡¤Washer
¡¤Main clutch case assy
¡¤Washer
¡¤Clutch shoe assy
¡¤There are two indents on the vice clutch case.
When installing the main clutch case, one of the
indents should align with the main clutch gear.
12) Installment:
¡¤Locking washer ¢Ù
¡¤Nut ¢Ú(Main clutch)
¡¤Be sure to use new locking washer
¡¤The locating plate of locking washer should
be installed in the indent of clutch shoe assy.
Caution
13)Tight up:
¡¤Nut ¢Ú(Main clutch)
Caution
Fasten the clutch shoe assy, then tighten up nut.
Caution
14)Bend the locking plate ¢Ûof locking washer.
¢Ú
¢Ù
¢Ú
¢Ù
- 186 -
