All the unit about the value is mm.
2) For example:
If¡°+0.02¡±is engraved on the output gear.
that is : =42+0.02=42.02
If¡°41.45¡±is engraved on the left crankcase
So the washer thickness is :
A=42.02-41.45=0.57mm
3) The following is prepared thickness of washer
(mm):
2. Choose washer
¡¤When changing the crankcase or output gear,
adjust output gear washer
1) Calculate the washer thickness of output gear
by following formula¡°A¡±:
A
A
=Theory installing distance 42 of output gear
adds the value engraved on the output gear.
is the value engraved on crankcase.
b
A =a-b
B =d-c-e-f
C =d-g-h-i
D =j+c-e-B-k-1-0.25
¢ÙLeft crankcase
¢ÚOutput gear
¢ÛForward shift gear
¢ÜOutput shaft
¢ÝReverse gear
¢ÞRear cover
Changed parts
Crankcase
Output gear
Forward gear
Reverse gear
Rear cover
Output shaft
Washer needed to be adjusted
A
A
B
B
D
C D
C D
C D
D
Washer thickness of output gear:
A= a - b
0.2
0.3
0.4
0.5
a
a
Caution
- 193 -
