ATV 200 - Page 28

Rear fender and rear luggage carrier
Left&right foot rest and frame
Left&right foot rest and frame
Supporting weldment in foot rest and bracket weldment
Rear rim and hub
Rear wheel axle and nut
Rear brake cam arm and cam shaft
Rear brake shoe and rear axle housing
Rear wheel fork and frame(left)
Rear wheel fork and frame(right)
Rear arm shaft and nut(right)
Rear wheel fork unit and rear driving gearbox units
Rear wheel axle bushing and driving gearbox units
Rear shock absorber(upper)and frame
Lower cover of gearbox
Rear wheel axle bushing and rear wheel fork unit
Fuel tank and frame
Oil draining bolt of rear driving gearbox
Oiling bolt of rear driving gearbox
Locking component and
location of ATV body
Name of
component
Size of
thread
Q’ty
Tightening torque of
fastener of ATV body
Remark
M8 ¡Á16
M6 ¡Á20
M10¡Á22
M8 ¡Á16
M8 ¡Á16
M10¡Á1.25
M16
M6 ¡Á30
M8¡Á1.25
M22¡Á1.25
M22¡Á1.5
M22¡Á1.5
M22¡Á1.5
M12 ¡Á1.25 ¡Á25
M12¡Á75
M8 ¡Á12
M12 ¡Á1.25 ¡Á25
M6 ¡Á35
M12¡Á1.25
M12¡Á1.25
Bolt
Bolt
Bolt
Bolt
Bolt
Nut
Nut
Nut
Bolt
Bolt
Bolt
Nut
Nut
Bolt
Bolt
Bolt
Bolt
Bolt
Bolt
Bolt
2
2
4
2
4
8
2
1
4
1
1
1
4
4
1
2
4
2
1
1
34
7
65
30
30
55
150
9
28
130
6
130
55
55
50
17
103
10
23
23
3.4
0.7
6.5
3
3
5.5
15
0.9
2.8
13
0.6
13
5.5
5.5
5
1.7
10.3
1
2.3
2.3
25
5.1
47
22
22
40
110
6.5
20
94
4.3
94
40
40
36
12
74
7.2
17
17
Nm
m.kg
ft.lb
- 22 -
