23-66
PPC Manual Revision 1
Chapter 23: D Registers (Holding Registers)
Register
No.
Description Range and meaning of value
D5713
PCMD_L1
Loop-1 active color PV display switch
0: Fixed in white
1: Fixed in red
4: L
5
: L
8: SP deviation (Within deviation: white, Out of
9: SP deviation (Within deviation: red, Out of deviation:
D5714
PCH_L1
Loop-1 PV color change high limit
Set a display value when in PV limit or SP deviation.
Decimal point position depends on the input type.
D5715
PCL_L1
Loop-1 PV color change low limit
D5716
PCMD_L2
Loop-2 active color PV display switch Same as D5713
D5717
PCH_L2
Loop-2 PV color change high limit
Same as D5714
D5718
PCL_L2
Loop-2 PV color change low limit
D5719
BAR1
Upper bar-graph display registration
0: Disable
1: OUT
2: Not used
3: PV
4: SP
5: Deviation
6: Loop-2 OUT
7: Not used
8: Loop-2 PV
9: Loop-2 SP
10: Loop-2 deviation
11 to 16: Disable
17: Not used
18: PV terminals analog input
19: RSP terminals analog input
20: Not used
21: Not used
22: Not used
23: Time event and alarm status *
*: For BAR1 only
D5720
BAR2
Lower bar-graph display registration
D5721
BDV_L1
L
oop-1 bar-graph deviation display band
0
D5722
BDV_L2
L
oop-2 bar-graph deviation display band
