23-57
PPC Manual Revision 1
Chapter 23: D Registers (Holding Registers)
Input Setting (D5101 to D5300)
Register
No.
Description Range and meaning of value
D5101
IN
PV input type
0: OFF
5: T
WRE: W97Re3-W75Re25
D5102
UNIT
PV input unit
0
D5103 DP PV input decimal point position
0: No decimal place
1: One decimal place
2: Two decimal places
3: Three decimal places
4: Four decimal places
D5104
RH
Maximum value of PV input range
Depends on the input type.
- For temperature input -
-
For voltage / current input -
Set the range of a voltage / current signal that is applied.
The scale across which the voltage / current signal is actually
controlled should be set using the maximum value of input
D
5105
RL
Minimum value of PV input range
D5106
SDP
P
V input scale decimal point position S
ame as D5103
D5107
SH
Maximum value of PV input scale
-
D5108
SL
Minimum value of PV input scale
D5109
BSL
PV input burnout action
0
D5110
RJC
PV input reference junction
compensation
0
D5111
ERJC
PV input external RJC setpoint -10.0 to 60.0°
C
D5112
A.BS
PV analog input bias -
D5113
A.FL
0: OFF
1 to 120 s
D5114
A.SR
PV analog input square root
extraction
0
To Next Page
