PPC Manual Revision 1
Chapter 23: D Registers (Holding Registers)
Key Operation Setting, Display Function Setting, and SELECT Display Setting (D5701 to D5800)
Register
No.
Description Range and meaning of value
D5701
F1
*1 User function key-1 action setting
0
2
12: LCL2
22:
L
oop-2 setting values are unavalable in Single-loop control.
D5702
F2
*1 User function key-2 action setting
D5703
Fn
*1 User function key-n action setting
D5704
A/M-K
*1 A/M key action setting
0
D5711
DVB_L1
Loop-1 deviation display band
Permits a change in the span of deviation shown on
the front-panel deviation monitor.
D5712
DVB_L2
Loop-2 deviation display band
*1: Same parameter exists in other menu. “-K” is added to the end of the parameter in KEY
menu.
