23-37
PPC Manual Revision 1
Chapter 23: D Registers (Holding Registers)
Loop-2 SP and Alarm Setpoint Setting of Groups 1 to 8 (D3601 to D3800)
Register
No.
Description Range and meaning of value
D3601
SP_L2_1
Target setpoint of group 1
D3602
D3603
PIDN_L2_1
PID number selection of group 1
Set a PID group number to use.
D3604
A1_L2_1
Alarm-1 setpoint of group 1
Set a display value of setpoint of PV alarm, SP
alarm, deviation alarm, output alarm, or velocity
alarm.
-19999 to 30000 (Set a value within the input
Decimal point position depends on the input type.
D3605
A2_L2_1
Alarm-2 setpoint of group 1
D3606
A3_L2_1
Alarm-3 setpoint of group 1
D3607
A4_L2_1
Alarm-4 setpoint of group 1
D3608
A5_L2_1
Alarm-5 setpoint of group 1
D3609
A6_L2_1
Alarm-6 setpoint of group 1
D3610
A7_L2_1
Alarm-7 setpoint of group 1
D3611
A8_L2_1
Alarm-8 setpoint of group 1
D3612 to D3620
D3621 to
D3631
SP_L2_2 to A8_L2_2
Target setpoint of group 2 to Alarm-8
setpoint of group 2
Same as D3601 to D3611
D3632 to D3640
D3641 to
D3651
SP_L2_3 to A8_L2_3
Target setpoint of group 3 to Alarm-8
setpoint of group 3
Same as D3601 to D3611
D3652 to D3660
D3661 to
D3671
SP_L2_4 to A8C_L2_4
Target setpoint of group 4 to Alarm-8
setpoint of group 4
Same as D3601 to D3611
D3672 to D3680
D3681 to
D3691
SP_L2_5 to A8_L2_5
Target setpoint of group 5 to Alarm-8
setpoint of group 5
Same as D3601 to D3611
D3691 to D3700
D3701 to
D3711
SP_L2_6 to A8_L2_6
Target setpoint of group 6 to Alarm-8
setpoint of group 6
Same as D3601 to D3611
D3712 to D3720
D3721 to
D3731
SP_L2_7 to A8_L2_7
Target setpoint of group 7 to Alarm-8
setpoint of group 7
Same as D3601 to D3611
D3732 to D3740
D3741 to
D3751
SP_L2_8 to A8_L2_8
Target setpoint of group 8 to Alarm-8
setpoint of group 8
Same as D3601 to D3611
D3752 to D3800
