23-38
PPC Manual Revision 1
Chapter 23: D Registers (Holding Registers)
Loop-2 SP-related Setting (D3801 to D3900)
Register
No.
Description Range and meaning of value
D3801
RMS_L2
Remote input method
R
COM is not displayed if the communication function
parameter is not displayed.
D3802
RFL_L2
R
0
1 to 120 s
D3803
RT_L2
Remote input ratio
SP = Remote input x RT + Remote input bias
0.001 to 9.999
D3804
RBS_L2
Remote input bias -
D3805
UPR_L2
SP ramp-up rate
Used to prevent SP from changing suddenly.
Set a ramp-up rate or ramp-down rate per hour or
minute. Set a time unit using the parameter TMU.
D3806
DNR_L2
SP ramp-down rate
D3807
TMU_L2
SP ramp-rate time unit
0: HOUR (Ramp-up rate or ramp-down rate per
1: MIN (Ramp-up rate or ramp-down rate per
D3808 to D3809
D3810
SPT_L2
SP tracking selection
Tracking is performed when the mode changes
from Remote to Local. (The local setpoint keeps
1: ON
D3811
PVT_L2
PV tracking selection
Causes the setpoint to keep track of the PV so the
setpoint automatically reverts to its original value at
a preset rate of change. The UPR, DNR, and TMU
are used in combination.
Operating conditions:
1M
1: ON
D3812 to D3900
To Next Page
