Chapter 20: Modbus Communication

03 Reading multiple D registers




 


Element
Message
start mark
(:)
Address No.
(ADS)
Function code
(0x03)
Register
start No.
Number
of read
registers
Error
check
Message
end mark
(CR+LF)
  1 1 2 2 2 


1 2 2 4 4 2 2


Element
Message
start mark
(:)
Address No.
(ADRS)
Function code
(0x03)
Byte count
(Note 1)
Register
content

  1 1 1 2 


1 2 2 2 4 

Register
content
Error
check
Message
end mark
(CR+LF)
2 2 
4 2 2

