24-8
PPC Manual Revision 1
Chapter 24: I Relays (Coil)
System Error, Input Error, and Operation Mode (4001 to 4320)
I relay No. Symbol Event
4001 to 4016
SYSTEM_ERR to
CTLPA_ERR
4033 to 4048
E1_ERR to COM_E3_
ERR
4049 to 4064
4065 to 4128
ADERR to ADBO
PVBO_L1 to ATERR_L1
PVBO_L2 to ATERR_L2
4193 to 4208
4225 to 4240
4241
0: OFF
4256 FAIL_ALARM
0: FAIL alarm
4257 to 4320 Free area
Alarm, Alarm Latch (4321 to 4576)
I relay No. Symbol Event
4321 to 4336 ALM1_L1~ALM8_L1
4337 to 4352 ALM1_L2~ALM8_L2
4353 to 4368 ALO1_L1 to ALO8_L1
4369 to 4384 ALO1_L2 to ALO8_L2
4385 to 4400
ALO1LA1_L1 to
ALO8LA1_L1
4401 to 4416
ALO1LA1_L2 to
ALO8LA1_L2
4417 to 4432
ALO1LA2_L1 to
ALO8LA2_L1
4433 to 4448
ALO1LA2_L2 to
ALO8LA2_L2
4449 to 4464
ALO1LA3_L1 to
ALO8LA3_L1
4465 to 4480
ALO1LA3_L2 to
ALO8LA3_L2
4481 to 4496
ALO1LA4_L1 to
ALO8LA4_L1
4497 to 4512
ALO1LA4_L2 to
ALO8LA4_L2
4513 ALOLA_RLS
0: OFF
1: Latch release
Automatically returned to "0".
4514 ALM_WAIT
0: OFF
1: Forced stand-by
Automatically returned to "0".
