11.1.8 Changing Deviation Display Lamp Action
Description


Lit when exceeding SP + (deviation display band).
Lit when exceeding SP
– (deviation display band).
Lit when within (Deviation display band).

PV
SP
+ (deviation display band)
Deviation display band
SP
– (deviation display band)
SP
Deviation indicator is lit.
Setting Details
Parameter
symbol
Name
Display
level
Setting range Menu symbol
DVB
 




