17-23
PPC Manual Revision 1
Chapter 17: Software Setting Flow and Navigation
17.9 Downloading Data
CAUTION
Do not download data while the controller is being used for control loop.
Otherwise, it may cause a sudden change of the control output.
Be sure to disconnect the main unit from the target unit before downloading
data.
Note
Before downloading, it is recommended to compare the file data with the controller data to
identify any potential changes. See Section 17.11 Comparing Data with Controller’ s Data.
Download All
Procedure
1.
2.
3.
After clicking the [Download All] button, follow the prompts that are displayed.
If the data in use has not yet been saved, a dialog box asking if you want to save data
appears.
▪
To save the data and continue the process, click [Yes].
▪
To continue the process without saving the data, click [No].
▪
To stop the process, click [Cancel].
To Next Page
