Automationdirect.com prosense PPC5 Series User Manual

23-85
PPC Manual Revision 1
Chapter 23: D Registers (Holding Registers)
Constant Register (D7301 to D7330)
Register
No.
Description Range and meaning of value
D7301
to
D7330
K01 to K30
K01 data register to K30 data
register
K01 to K20: -32768 to 32767
K21 to K30: 0 to 65535
Input Range / Scale (D7501 to D7600) (Read only)
Register
No.
Description Range and meaning of value
D7501 DP_R PV input decimal point position 
D7502 RH_R Maximum value of PV input range 
D 7503 RL_R Minimum value of PV input range 
D 7504
D7505 SDP_R P V input scale decimal point position S 
D7506 SH_R Maximum value of PV input scale 
D7507 SL_R Minimum value of PV input scale 
D7508
D7509 DP_E1_R R SP remote input decimal point position S 
D7510 RH_E1_R
Maximum value of RSP remote
input range

D 7511 RL_E1_R
Minimum value of RSP remote input
range

D 7512
D7513 SDP_E1_R
R SP remote input scale decimal point
position
S 
D7514 SH_E1_R
M aximum value of RSP remote input
scale
S 
D7515 SL_E1_R
M inimum value of RSP remote input
scale
S 
D7516
