Automationdirect.com prosense PPC5 Series - PV Input Wiring

1-8
PPC Manual Revision 1
1.4.2 PV Input Wiring
CAUTION








TC Input RTD Input (3-wire system)
203
202
TC
–
+
Compensating lead wire
Grounding
Shield
PV
203
202
201
RTD
A
B
b
Lead wire resistance per wire of
10 Ω or less. Make the resistance
of the three wires equal.
A
b
B
Grounding
Shield
PV
DC Voltage (mV, V) Input DC Current (mA) Input
203
202
–
+
+
–
DC voltage
Grounding
Shield
PV
204
203
–
+
+
–
DC current
Grounding
Shield
PV
Use







Chapter 1: Installation and Wiring
