23-41
PPC Manual Revision 1
Chapter 23: D Registers (Holding Registers)
Loop-2 PID Setting of Groups 1 to 8 and R (D4101 to D4600)
Register
No.
Description Range and meaning of value
D4101
P_L2_1
Proportional band of group 1
0.0 to 999.9%
When 0.0% is set, it operates as 0.1%.
D4102
I_L2_1
Integral time of group 1
1 to 6000 s
D4103
D_L2_1
Derivative time of group 1
1 to 6000 s
D4104
OH_L2_1
Control output high limit of group 1
D4105
OL_L2_1
Control output low limit of group 1
D4106
MR_L2_1
Manual reset of group 1
Enabled when integral time is OFF.
The manual reset value equals the output value
when PV = SP.
-5.0 to 105.0%
D4108 to D4110
D4111
DR_L2_1
Direct/reverse action switch of group 1
0: RVS: Reverse action
1: DIR: Direct action
D4112
D4123 to D4450
To Next Page
