23-70
PPC Manual Revision 1
Chapter 23: D Registers (Holding Registers)
Lock Setting (Key Lock/Menu Lock) (D5801 to D5900)
Register
No.
Description Range and meaning of value
D5801
U.SP_L1
Loop-1 SP Display lock
0
D5802
U.SP_L2
Loop-2 SP Display lock
D5803
U.OUT_L1
Loop-1 OUT Display lock
D5804
U.OUT_L2
Loop-2 OUT Display lock
D5808
U.TSP_L2
Loop-2 TSP Display lock
D5809
U.PID_L1
Loop-1 PID Number Display lock
D5810
U.PID_L2
Loop-2 PID Number Display lock
D
5812
U.PV1
PV2/PV1 Display lock
D5813
U.PV2
PV1/PV2 Display lock
D5814
U.PV
PV Analog Input Display lock
D5815
U.RSP
RSP Analog Input Display lock
D5818
COM.W
Communication write enable/disable
0
D5819
DATA-L
*1 Front panel parameter data key lock
0
D5820
A/M-L
*1 Front panel A/M key lock
D5821
RUN-L
*1 Front panel RUN key lock
D5822
RST-L
*1 Front panel RST key lock
D5823
PTN-L
*1 Front panel PTN key lock
D5824
MODE-L
*1 Front panel MODE key lock
D5825
U.TSP_L1
Loop-1 TSP Display lock
0
D5826
U.TM
Remaining Segment-tim Display lock
D5827
D5828
U.RCY
Remaining Repetition Display lock
D5829
D5830
U.AL_L1
Loop-1 Alarm-5 to -8 Dsiplay lock
D5831
CTL-L
*1
[CTL] menu lock
D5832
PV-L
*1
[PV] menu lock
D5833
RSP_E1-L
*1
D5836
MPV_L1-L
*1
Loop-1 [MPV] menu lock
D5837
MPV_L2-L
*1
Loop-2 [MPV] menu lock
D5838
OUT-L
*1
[OUT] menu lock
D5841
R485_E3-L
*1
D5843
ETHR_E3-L
*1
D5847
KEY-L
*1
[KEY] menu lock
D5848
DISP-L
*1
[DISP] menu lock
D5849
CSEL-L
*1
[CSEL] menu lock
D5850
KLOC-L
*1 [KLOC] menu lock
D5851
DI.SL-L
*1
[DI.SL] menu lock
D5852
DI.NU-L
*1
[DI.NU] menu lock
*1: Same parameter exists in other menu. “-L” is added to the end of the parameter in KLOC menu or MLOC menu.
To Next Page
