Chapter 23: D Registers (Holding Registers)
Loop-2 operation parameter
PID setting (Menu: PID)
D-Reg
No.
Ref.
No.
H No.
Register
symbol
R/W
D-Reg
No.
Ref.
No.
H No.
Register
symbol
R/W
D4401 44401 1130
P_L2_7
R/W D4451 44451 1162
P_L2_8
R/W
D4402 44402 1131
I_L2_7
R/W D4452 44452 1163
I_L2_8
R/W
D4403 44403 1132
D_L2_7
R/W D4453 44453 1164
D_L2_8
R/W
D4404 44404 1133
OH_L2_7
R/W D4454 44454 1165
OH_L2_8
R/W
D4405 44405 1134
OL_L2_7
R/W D4455 44455 1166
OL_L2_8
R/W
D4406 44406 1135
MR_L2_7
R/W D4456 44456 1167
MR_L2_8
R/W
D4408 44408 1137 D4458 44458 1169
D4411 44411 113A
DR_L2_7
R/W D4461 44461 116C
DR_L2_8
R/W
D4412 44412 113B D4462 44462 116D
D4423 44423 1146 D4473 44473 1178
Loop-2 operation parameter
PID setting (Menu: PID)
D-Reg
No.
Ref.
No.
H No.
Register
symbol
R/W
D4501 44501 1194
P_L2_R
R/W
D4502 44502 1195
I_L2_R
R/W
D4503 44503 1196
D_L2_R
R/W
D4504 44504 1197
OH_L2_R
R/W
D4505 44505 1198
OL_L2_R
R/W
D4506 44506
1199
MR_L2_R
R/W
D4507 44507 119A
HYS_L2_R
R/W
D4508 44508 119B
D4511 44511 119E
DR_L2_R
R/W
D4512 44512 119F
D4523 44523 11AA
Loop-2 operation parameter
Control action-related setting (Tuning menu: TUNE) (Zone control menu: ZONE)
D-Reg
No.
Ref.
No.
H No.
Register
symbol
R/W
D-Reg
No.
Ref.
No.
H No.
Register
symbol
R/W
D4601 44601 11F8
SC_L2
R/W D4651 44651 122A
D4602 44602 11F9 D4652 44652 122B
D4603 44603 11FA
AT.TY_L2
R/W D4653 44653 122C
RP1_L2
R/W
D4604 44604 11FB
AT.OH_L2
R/W D4654 44654 122D
RP2_L2
R/W
D4605 44605 11FC
AT.OL_L2
R/W D4655 44655 122E
RP3_L2
R/W
D4606 44606 11FD
AT.BS_L2
R/W D4656 44656 122F
RP4_L2
R/W
D4607 44607 11FE D4657 44657 1230
RP5_L2
R/W
D4613 44613 1204
GW_L2
R/W D4658 44658 1231
RP6_L2
R/W
D4614 44614 1205
GG_L2
R/W D4659 44659 1232
RP7_L2
R/W
D4615 44615 1206 D4660 44660 1233
RHY_L2
R/W
D4626 44626 1211
AR_L2
R/W D4661 44661 1234
RDV_L2
R/W
D4627 44627 1212
OPR_L2
R/W D4662 44662 1235
D4628 44628 1213
OLMT_L2
R/W
D4629 44629 1214
D4631 44631 1216
MPON_L2
R/W
D4632 44632 1217
MPO1_L2
R/W
D4633 44633 1218
MPO2_L2
R/W
D4634 44634 1219
MPO3_L2
R/W
D4635 44635 121A
MPO4_L2
R/W
D4636 44636 121B
MPO5_L2
R/W
D4637 44637 121C
