Page | 9 of 105
AVR8414 Operation Manual – Rev O
The basic function of each bezel key follows:
Enter – Press to acknowledge entries where necessary. The Encoder Knob can also
be used to acknowledge entries.
Clear – Press to clear or cancel an operation or backup. The Clear button is also a
back button for the On-screen Display (OSD).
Rewind – Press this to skip backward in 10x, 20x, 30x, 40x, and 50x speeds.
Play/Pause – Press to toggle between play and pause operation.
Fast Forward – Press to skip forward in 10x, 20x, 30x, 40x, and 50x speeds.
Day/Night – Press to switch the display between day and night modes.
Luminance – Press to increase or decrease brightness of display and keys.
Record – Press to allow one or more video signals to be recorded.
Stop – Press to stop recording.
Line Select Key 1 – Press to access video inputs for recording/playback.
Line Select Key 2 – Press to access video inputs for recording/playback.
Softkey 1 – Press to access the file list from the Front Display and OSD.
Softkey 2 – Press to access system status and detail pages.
Softkey 3 – Press to access live action record and playback controls.
Softkey 4 – Press to turn the OSD menu on and off.
