Page | 71 of 105
AVR8414 Operation Manual – Rev O
Advanced Features
KLV Overlay
The AVR8414 offers the capability of viewing KLV data as an overlay of the recorded video.
The recorded video must contain certain KLV data fields in order for the data to be displayed
(Figure 76). The data fields the video is capable of displaying are described in the table below.
The tags correspond to MISB Standard 0601.2. If KLV data is present in the video, this feature
can be enabled by toggling through the OSD status bars using the encoder knob as described
in the Quick Start, Encoder Knob section of this manual.
Table 7 – KLV Data Fields
Sensor Horizontal Field of View
