Product Specifications
AVR8414
Height
1.5”; 38.1 mm
Width
5.75”; 146.1mm
Depth
8.14”; 206.8mm
Weight
1.4Lbs
Operating Range
-45 to +71 ˚C; -49 to 159.8
º
F
Storage Temperature Range
-55 to 85
º
C; 14 to 149
º
F
Video (RS-170)
4 Inputs; 1 Outputs
SMPTE-292
2 Inputs; 1 Output
Ethernet 10/100
1 Port
Signal Types
NTSC 720 x 480
PAL 720 x 576
HD 720p @ 25, 29.97, 30, 50, 59.94, 60 fps
HD 1080i @ 25 (50 fields/sec), 29.97 (50.94 fields/sec), 30
(60fields/sec) fps
HD 1080p @ 25, 30, 29.97, 50, 60, 59.94 fps
Metadata
KLV Stanag 4609 / MISB
Control
RS-232
RS-422
CAN bus
Discrete
Ethernet 10/100
Usable Internal Memory
54 GB
Power Input
28 VDC
Typical Power Draw
With SATA –16.8 Watts
Without SATA – 14 Watts
Recommended Breaker Size
2 Amps @ 28 Volts
Option 1 Option 2
Audio Stereo or
1 Input; 1 Output
Audio Mono
1 Inputs; 1 Output
Audio Mono *
2 Inputs; 2 Outputs
Discretes
3 Inputs; 1 Output
Discretes
3 Inputs
* Software configurable
