Figure 21: Camera scope covers all seats
All cameras should be at a height to ensure eye contact between local and remote participants.
Try positioning the camera between the two monitors either directly above or below them, at a
distance which captures all the seats.
Caution:
Do not place the camera on top of the XT Codec Unit. It can cause the system to overheat.
Place chairs so that you and other participants appear in full frame of the cameras, in the
middle of the monitors.
For larger rooms, a single XT Series can manage more than one camera. For more
information, see Connecting Cameras or DVD players on page 48.
• Microphone positions
Place the Microphone Pod at the center of the table, in front of the participants.
If you deploy the One-way Microphone Pod, note it has a limited three meter 180° range, so be
sure to place all participants on one side of the microphone. The Three-way Microphone Pod
picks up sound up to three meters away at all angles (360°).
Setting Up the XT Series Hardware
44 Avaya Scopia
®
XT Series Deployment Guide April 2015
