Type of
Microphon
e
Optimal Room
Size
Advantages Disadvantages Microphone
Specifications
Typically
Used With
Audio
Mixer
When connected, you
can also transmit PC
audio
Separate echo
canceling
configuration
microphones and
audio mixer
Related Links
Connecting Microphones and Speakers to the XT Series on page 59
Connecting a Microphone to the XT Series
About this task
Select the microphones best suited to your deployment (see
Choosing a Microphone for Your XT
Series on page 59), and ensure all participants are seated within the range of one of the
microphones. To determine the best microphone positioning, see Planning the Optimal Room
Setup on page 42.
More complex setups, like setting up an auditorium or mixing different types of microphones, may
require an audio mixer (for example Clear One mixers). An audio mixer connects multiple
microphones (or other audio inputs) to generate a single audio stream. Using an audio mixer
requires you disable echo-cancellation on the XT Series (see
Configuring Microphones on
page 104) and then enable it either on the audio mixer, or (ideally) on each microphone. The audio
mixer must have either an analog audio I/O (mini jack 3.5”) connector or a digital optical (mini-
TOSlink) connector.
The Scopia
®
XT Executive uses the microphone embedded in the camera by default. If you connect
an additional microphone, the embedded microphone is disabled.
Procedure
1. Connect a microphone to the XT Codec Unit as follows:
•
The dedicated microphone
port is for the digital Three-way Microphone Pod. The
XT5000 Series can support two of these microphones daisy-chained.
• The USB port is used for USB headsets, or for a USB camera with a built-in microphone
(lower USB only).
•
The audio input port
is for:
- The analog One-way Microphone Pod or any other analog microphone with a 3.5mm
jack.
- A third-party digital microphone with a mini-TOSlink connector.
- Audio mixers like those from Clear One. An audio mixer connects multiple microphones
(or other audio inputs) to generate a single audio stream.
- A computer audio-out connection or line audio connection.
