Troubleshooting
100 AVENTICS | Marex 3D | R417003094–BDL–001–AA
The error entries are displayed in a continuous list. Every error
is indicated in two lines as plain text with an error code. If
several errors have occurred, you can scroll through the error
list by turning the SELECT button.
A down arrow <↓> indicates that you can still scroll down.
An up arrow <
↑> indicates that you can still scroll up.
Error code systematics The error display shows all errors in the sequence of their
occurrence. The latest errors are always displayed on top of the
list
.
Dev 6 NMEA 033*W< >
new
HW 1 OS3D 003/L< >
CAN 2 001*L< >
...
ESC < >
old
1 Source of error
2 Reference number of the source (to be found in the project
documentation). Example CAN bus "1" = internal bus, "2" =
cross communication, "3" = NMEA
3 Device type, example "NMEA" = compass
4 Error number
5 Error status
6 Error state: warning / light alarm
