Troubleshooting
102 AVENTICS | Marex 3D | R417003094–BDL–001–AA
Error status
Error levels
Error message, example
When selecting an error in the display, that error is
automatically acknowledged. You can quit the display by
selecting "ESC" or by pushing the ESCAPE-key. Errors
which are no longer active will always be deleted when
quitting the display.
10.5.3 Error messages
The following tables give an overview on the errors which can
be displayed at the Marex 3D Controller. Separate tables are
available for the relevant devices: joystick type 531, Side Power
thrusters, module T750, compass (NMEA), Marex 3D Controller
and general thruster errors.
* Error is active
/ Error has disappeared
L "Light" alarm: The Alarm LED is ON, the buzzer sounds
continuously. The relevant device can no longer be
actuated by Marex3D.
W Warning: The Alarm LED is ON, the buzzer is off. The
relevant device is still operational, but must be
examined nevertheless.
Dev 7 SPow 033*W
Switch Stern System
02.12.14 13:45:30
ESC < >
Table 9: Error messages in the 3D Controller
Source Device type Error No. Error state Text message Further information Remedial action
Dev uJsk 001 Light x.yyy guarding fail Joystick does not
respond.
Check cabling and
voltage
Dev uJsk 036 Light x.yyy Supp. Volt. Supply voltage out of
admissible range.
Check voltage
