Troubleshooting
AVENTICS | Marex 3D | R417003094–BDL–001–AA 101
English
10.5.2 Error specifications
Sources
Source reference numbers
Device specification "Dev"
Hardware specification "HW"
Error number
The error number must be considered together with the error
source and relevant device.
Dev Device error (example: joystick type 530)
HW Hardware error (example: Marex 3D, control unit)
THR Thruster (external system)
CAN CAN bus error
Par Parameter error
Sys System error (parameterization)
Dev xx Reference number referring to the list of devices in the
project documentation
HW 1 Marex 3D hardware
CAN x 1 ... 3 indicates the number of the CAN bus
uJst Joystick / Marex 3D CAN I/0 light
OpMd Operating module
SPow Side Power/S-Link
T750 WAGO
uSlv Virtual device
PROP Propulsion system
Jstk Joystick CAN
AO Analog output
CAN CAN bus
Temp Temperature
Supl Supply voltage
