Appendix A: Table of Inputs and Outputs
Main Outputs Type Comments
Program-1 Stereo Main stereo bus (Usually refered to as Program)
Program-2 Stereo Second stereo bus (Sometimes refered to as Audition)
Program-3 Stereo Third stereo bus (Sometimes refered to as Utility), signal post fader, before
on/off.
Program-4/Record Stereo Fourth stereo bus (Sometimes referred to as Auxiliary), signal pre-fader, before
on/off.
Aux Inputs and Outputs Type Comments
Aux Send-1 Output Stereo Aux send bus can be used for processing or independent mixes
Aux Send-2 Output Stereo Aux send bus can be used for processing or independent mixes
Aux Return-1 Input Stereo Allows processing to be folded back into a mix
Aux Return-2 Input Stereo Allows processing to be folded back into a mix
Monitor-related Outputs Type Comments
C/R Monitor Main Stereo Control room monitor speakers, source and level controlled by SS c/r monitor
control
C/R Monitor Direct Stereo Control room monitor output, source same as main, xed level output
Main Headphone Stereo Control room (board op) headphone, source and level controlled by SS head-
phone control
Studio Monitor Main Stereo Studio monitor speakers, source and level controlled by SS studio monitor con-
trol
Studio Headphone Talent Stereo Studio (talent) headpones, source same as main, xed level output, with
talkback
Studio Headphone Guest Stereo Studio (guest) headphones, source same as main, xed level output, no talkback
Preview Stereo Allows the connection of external powered speakers.
Talk to External Mono Allows board operator mic to talk to other devices, a logic command is associated
Talk to CR Audio Mono Allows the Talk to CR audio mix to drive an external destination
Monitor-related Inputs Type Comments
External Preview Input Stereo Allows an external path into the preview speakers, a logic command is associated
External Monitor Input 1 Stereo Allows an external source to be monitored by c/r or studio selectors
External Monitor Input 2 Stereo Allows an external source to be monitored by c/r or studio selectors
External Monitor Input 3 Stereo Allows an external source to be monitored by c/r or studio selectors
External Monitor Input 4 Stereo Allows an external source to be monitored by c/r or studio selectors
Source Inputs Type Comments
Microphone Input n Mono Typical installations have 4 or 8 microphone sources per studio
Analog Line Input n Stereo Typical installations have 16 analog line sources per studio
Digital Line Input n Stereo Typical installations have 16 digital line sources per studio
Source-related Outputs Type Comments
Feed-to-Source A n Mono Mono mix-minus output feeds the left side of a stereo connection. “Talk to...”
function enabled.
Feed-to-Source B n Mono Mono mix-minus output feeds the right side of a stereo connection. “Talk to...”
function disabled.
Individual Hdphone Feed n Stereo Individual headphone feed (for talent and guest mics) with *Talk to x* function
enabled.
