4: Element Operations • 52
©2008 Axia Audio — Rev. 3.0
The Select/Take knob, when rotated, scrolls
through the list of available audio sources that
can supply backfeed or mix-minus.
Automatic backfeeds audio from the Phone
bus when the channel is Off, and audio from
the Program-1 bus when the channel is On,
with mix-minus if needed.
Phone backfeeds audio from the Phone bus,
with mix-minus if needed.
Program 1 - Program 4 backfeeds audio
from the selected Program bus, with mix-mi-
nus if needed.
Aux Send 1 - Aux Send 4 backfeeds audio
from the selected Auxiliary bus, with mix-
minus if needed.
About the PHONE and PROGRAM 4 buses:
Element’s Program 4 mix bus is a special multi-
purpose bus that does several things at once to
make life easier for the operator.
Any source assigned to Program 4 also be fed
to the PHONE bus and sent to callers when the
channel is OFF and AUTO is selected as the
Feed To Source Mode. PHONE is an internal bus
which does not feed a separate output; instead,
it picks up the Program 4 audio pre-fader and
pre-On/Off and backfeeds them to an PHONE
sources.
Sources assigned to Program 4 are also sent to
the RECORD bus, a special xed-level output
that can be used to feed recording devices.
Rotating the Dim knob allows the operator to
adjust, in dB, the amount by which the studio
monitors are dimmed when this fader channel’s
Talkback key is pressed.
Pressing Feed to Source or Options a second
time exits this menu.
Delay Section
These keys can be used to provide from-the-board
control of an external profanity delay unit using one of
Element’s GPIO ports (refer to Chapter 3: Configuring
GPIO for instructions on GPIO setup).
The keys provide for remote activation of Dump,
Exit, Pause and Engage functions, respectively.
»
*
*
*
*
»
»
Monitor Section
This controls in this section provide direct operator
access to monitor selection and volume controls.
Monitor 1 Knob + Source Keys
This knob, at the bottom left of the Monitor section,
controls the selection and volume of the source heard
in the Monitor 1 speakers (typically the Control Room
monitors).
Rotate the knob to vary the gain of the Monitor
1 speakers.
Use the Direct Selection Keys in the column
directly above the Monitor 1 knob to send the
output of Program 1 - Program 4, Aux Send
A - Aux Send D, or the two External monitor
sources to the Monitor 1 speakers. These keys
light to denote the selected source.
You can listen to any frequently-used audio
stream in your facility instantly (such as a net-
work feed, off-the-air monitor or another studio’s
Program output) by assigning it to one of the two
External selector keys - like preset buttons on a
car radio.
Programming the External Monitor Selec-
tor keys: If you press and hold either of these
keys for ve seconds, a list of available audio
streams will pop up onscreen. You can then
scroll through this list and select the source you
want to hear in the monitors when that key is
pressed. Each External key is independently
programmable.
You can also pre-program the source assigned
to these keys when you construct or capture
Show Proles, using the options available on the
Monitor page of the Show Prole setup menu.
Headphone Knob + Source Keys
This knob, at the bottom right of the Monitor section,
controls the selection and volume of the source heard in
the board operator’s headphones.
Rotate to vary the gain of the Headphone feed.
Use the Direct Selection Keys in the column di-
rectly above the Headphones knob to send the
output of Program 1 - Program 4, Aux Send
A - Aux Send D, or the two External monitor
•
»
»
»
•
»
»
