Axia Element - Page 157

Working With Phone Hybrids • 147
©2008 Axia Audio — Rev. 3.0
Figure D-5: Call Controller + 2-Phone Fader Module
Status Symbol indicates backfeed
(mix-minus) to hybrid is active
Transfer key Block All key
Line selection
keys, Hybrid 1
Line selection
keys, Hybrid 2
Hold key, Hybrid 1 Hold key, Hybrid 2
Hybrid 1 fader Hybrid 2 fader
Drop key, Hybrid 1 Drop key, Hybrid 2
Next key
