Banner iVu Plus TG Gen2 User Manual

There are only two Blemish sensors on the current inspection; Blemish3 location will be all zero on the customizable space.
The customizable space had not reserved a Match sensor, Match1 from the inspection will not be outputted on the
customizable space.
9.6.5 Input and Output Flags
The Input Bits are used to command execution of basic functions. The Output Bits are used to push single bit outputs from
the iVu Sensor to the PLC. The 32 bits of iVu output can also be accessed using the bits of the first two Output Registers
(Input Bits ACK Register(word 0) and Output Bits Register (word1)).
Input Bits Register
Command
Set BCR
Mask
Set BCR
String
Trigger
Teach
Latch
Product
Change
Gated
T
rigger
Bit Position
123456789101112131415 0
Input Bits ACK Register
Command
ACK
Set BCR
Mask ACK
Set BCR
String ACK
Trigger
ACK
Teach
Latch
ACK
Product
Change
ACK
Gated
T
rigger
ACK
Bit Position
123456789101112131415 0
Output Bits Register
Execution
Error
System
Error
Teach
Error
Missed
Trigger
Output 3 Output 2 Output 1
Read/
No Read
Pass/Fail
Ready
Latch
Ready
Bit Position
123456789101112131415 0
9.7 PROFINET
PROFINET
®
is a data communication protocol for industrial automation and processes. PROFINET IO defines how
controllers (masters) and peripheral devices (slaves) exchange data in real time.
The image sensor, iVu Plus TG Gen2 , supports PROFINET IO. The data communication protocol is TCP/IP; the data
transmission medium is copper wire; the PROFINET conformance class is CC-A.
NOTE: In this document, outputs from the iVu Plus TG Gen2 device are referred to as "inputs" to the
controller (PLC). Outputs from the controller (PLC) are referred to as "inputs" to the iVu Plus TG Gen2
device.
9.7.1 General Station Description (GSD) File
The General Station Description (GSD) file contains module information, such as:
•
Configuration data;
• Data information (pass count, inspection status, etc.); and
1
PROFINET
®
is a registered trademark of PROFIBUS Nutzerorganisation e.V.
2
CC-A ensures that the device has the minimum properties in regard to functionality and interoperability.
iVu Plus TG Gen2 Image Sensor
144 www.bannerengineering.com - Tel: 763.544.3164
