10.Copy the sensor configuration (that is, CONFIG.CFG) from the PC working directory to the USB flash drive (for
example <USB>:\BANNER\myName\CONFIG.CFG).
11.
Remove the USB flash drive from the PC, and connect it to the sensor.
12.Restore the configuration to the sensor.
a. Go to Main Menu > System > Configuration > Load Configuration.
b. Select the Configuration to restore.
c. Click the Load button to start the restore sensor configuration.
d. Reboot the sensor when the restore is complete.
10.2.2 How to Debug Using the Emulator from the USB Flash Drive
1. Plug a USB flash drive into the sensor.
2. Save the Inspection Logs to the sensor.
a. On the Main Menu > Inspection Logs > View Logs screen, click the Save icon to save the inspection
logs.
b. When prompted, select Yes to save sensor configuration along with the Inspection Logs. The location of
these files on the USB flash drive displays after the operation is completed—the Inspection Logs are saved
in <USB>:\BANNER\<SENSOR_NAME>\InspLog and the sensor configuration is saved in <USB>:\BANNER
\<SENSOR_NAME>. For example, if the sensor name is myName:
Configuration File (CONFIG.CFG) path: <USB>:\BANNER\myName
Inspection Logs path: <USB>:\BANNER\myName\InspLog
NOTE: If the sensor has no name, the folder name is the first 8-characters of the serial
number.
3. Remove the USB flash drive from the sensor and insert it into an available USB port on a Windows PC that has the
iVu Emulator installed.
4.
Copy the iVuEmulator.exe program file to the USB flash drive in the same location as the CONFIG.CFG file (for
example, <USB>:\BANNER\myName).
5. Launch the <USB>:\BANNER\myName\iVuEmulator.exe program.
6. Set the Trigger option to Internal—
a. Go to Main Menu > Imager > Trigger, and select Internal.
b. Set the Trigger Interval as desired.
The iVu Emulator runs with the saved configuration using the saved Inspection Logs as images.
7. Make the desired adjustments.
8. Close the iVu Emulator program. All configuration changes are saved to the CONFIG.CFG file.
9. Remove the USB flash drive from the PC, and connect it to the sensor.
10.Restore the configuration to the sensor.
a. Go to Main Menu > System > Configuration > Load Configuration.
b. Select the Configuration to restore.
c. Click the Load button to start the restore sensor configuration.
d. Reboot the sensor when the restore is complete.
iVu Plus TG Gen2 Image Sensor
www.bannerengineering.com - Tel: 763.544.3164 199
