Modbus™ Communication DECS-200
7-10
Information
Category ID
Information
Category
Total # of
Reserved
Holding
Registers
Holding
Register
Address
Space
Number
Of Used
Registers
Access
Right
Data Types
Mapped To
Registers (Total #
Of Variables)
C12 Relays 120
48041 to
48160
83 RW UINT16: 83
C13
General
System
60 48161 to
48220
8 2 R
6 RW
UINT16: 6
UCHAR: 2
C14 FP Metering
Configuration
30 48221 to
48250
3 3 RW UINT16: 3
C15
Control System
Configuration
Group II
50 48501 to
48550
10 RW FLOAT: 4
DECS-200 REGISTER TABLE
Each data to be transmitted via Modbus network is identified by its holding register(s). The following
tables provide the complete list of holding register assignments and descriptions for the DECS-200. There
is a separate table for each information category.
Holding Registers for Information Category C1
Table 7-11. Information Category C1 (Product Information)
Registers Data Description Access
Data
Format
47001
1st character of the ASCII string of model information R- UI8
47002
2nd character of the ASCII string of model information R- UI8
47003
3rd character of the ASCII string of model information R- UI8
47004
4th character of the ASCII string of model information R- UI8
47005
5th character of the ASCII string of model information R- UI8
47006
6th character of the ASCII string of model information R- UI8
47007
7th character of the ASCII string of model information R- UI8
47008
8th character of the ASCII string of model information R- UI8
47009
Last character of the ASCII string of model information R- UI8
47010
1st character of the ASCII string of application program version
number
R- UI8
47011
2nd character of the ASCII string of application program version
number
R- UI8
47012
3rd character of the ASCII string of application program version
number
R- UI8
47013
4th character of the ASCII string of application program version
number
R- UI8
47014
5th character of the ASCII string of application program version
number
R- UI8
47015
6th character of the ASCII string of application program version
number
R- UI8
