2-24 Human-Machine Interface DECS-200
Screen: \GAIN\LIM_GAINS (3.3)
OEL Ki - integral gain coefficient used in the overexcitation limiter loop
OEL Kg - loop gain used in the overexcitation limiter
UEL Ki - integral gain coefficient used in the underexcitation limiter loop
UEL Kg - loop gain used in the underexcitation limiter
SCL Ki - integral gain coefficient used in the stator current limiter
SCL Kg - loop gain used in the stator current limiter
Controller Gains
Screen: \GAIN\CTL_GAINS (3.4)
PF Ki - integral gain coefficient used in the power factor controller
PF Kg - loop gain used for the power factor controller
Var Ki - integral gain coefficient used in the var controller
Var Kg - loop gain used for the var controller
V MATCH Kg - loop gain used for the voltage matching function
Metering
Screen: \METER\ADJUST (4.1)
1st metering field - displays any one of several metering quantities
2nd metering field - displays any one of several metering quantities
3rd metering field - displays any one of several metering quantities
SETPT - the present control mode operating setpoint
Screen: \METER\ALARM_MSG (4.2)
Reset Button - clears any displayed alarm messages (and returns to the ADJUST metering screen).
Protection
Screen: \PROT\UNDERFREQ (5.1)
CORNR FREQ - the corner frequency for the underfrequency curve
UF SLOPE - the slope of the underfrequency curve
Screen: \PROT\PROT_ENABL1 (5.2)
FIELD OV - field overvoltage detection enable
FIELD OC - field overcurrent detection enable
STATOR OV - generator output overvoltage detection enable
STATOR UV - generator output undervoltage detection enable
NO SENSING – loss of voltage sensing detection enable
NO SNS→FCR – transfer to FCR mode enable (when a loss of voltage sensing is detected). Loss of
voltage sensing detection must also be enabled for this feature to work.
Screen: \PROT\PROT_ENAB2 (5.3)
EX DIOD OD - exciter open diode detection enable
EX DIOD SD - exciter shorted diode detection enable
LOSS FIELD - enables and disables loss of field protection
Screen: \PROT\PROT_LEVL (5.4)
FIELD OV - field overvoltage threshold
FIELD OC - field overcurrent base value (100%)
STATOR OV - generator output overvoltage threshold
STATOR UV - generator output undervoltage threshold
