2-26 Human-Machine Interface DECS-200
Screen \LIMIT\OFFTAKOVR (6.4)
Off-line overexcitation limiter (takeover) settings.
OEL MAX CUR - off-line takeover overexcitation limiter maximum current threshold
OEL MIN CUR - off-line takeover overexcitation limiter minimum current threshold
OEL TD - off-line takeover overexcitation limiter time delay
Screen \LIMIT\ONTAKOVR (6.5)
On-line overexcitation limiter (takeover) settings.
OEL MAX CUR - on-line takeover overexcitation limiter maximum current threshold
OEL MIN CUR - on-line takeover overexcitation limiter minimum current threshold
OEL TD - on-line takeover overexcitation limiter time delay
Screen \LIMIT\UEL_CRV_X (6.6)
Underexcitation limiter real-power curve points.
PNT 1 WATTS - underexcitation limiter real-power curve point 1
PNT 2 WATTS - underexcitation limiter real-power curve point 2
PNT 3 WATTS - underexcitation limiter real-power curve point 3
PNT 4 WATTS - underexcitation limiter real-power curve point 4
PNT 5 WATTS - underexcitation limiter real-power curve point 5
Screen \LIMIT\UEL_CRV_Y (6.7)
Underexcitation limiter reactive-power curve points.
PNT 1 vars - underexcitation limiter reactive-power curve point 1
PNT 2 vars - underexcitation limiter reactive-power curve point 2
PNT 3 vars - underexcitation limiter reactive-power curve point 3
PNT 4 vars - underexcitation limiter reactive-power curve point 4
PNT 5 vars - underexcitation limiter reactive-power curve point 5
Screen \LIMIT\SCLIM (6.8)
Stator current limiter settings.
SCL HI LIM - stator current limiter high current setpoint
HI LIM TIME - stator current limiter time delay
SCL LO LIM - stator current limiter low current setpoint
System Parameters
Screen: \GEN\GEN_DATA (7.1.1)
RATED VOLT - generator rated output voltage
RATED CURR - generator rated output current
FREQUENCY - generator rated frequency
Screen: \EXCTR\EXCTR_DATA (7.2.1)
FIELD VOLT - rated field voltage
FIELD CURR - rated field current
POLE RATIO - ratio between exciter poles to the number of generator poles
Screen: \XFMRS\XFMR_DATA (7.3.1)
GEN PT PRI - generator sensing transformer primary voltage rating
GEN PT SEC - generator sensing transformer secondary voltage rating
BUS PT PRI - bus sensing transformer primary voltage rating
BUS PT SEC - bus sensing transformer secondary voltage rating
