6-14 Setup DECS-200
Verify transfer indications from the remote status indicators, front panel HMI, or
BESTCOMS interface ................................................................................................................... ________
Check the raise and lower limits ................................................................................................... ________
Verify raise/lower limit indications from the remote status indicators, front panel HMI,
or BESTCOMS interface............................................................................................................... ________
Control Gain Settings
Configure the initial gain settings.
Set the generator no-load setpoint in FCR mode (20% of exciter rated current recommended). ________
On the Control Gain screen, enter 200 in the FCR loop gain settings field.................................. ________
Enter the following recommended gain settings for OEL, UEL, and Var/PF.
Set OEL KI at 3 ............................................................................................................................. ________
Set OEL Kg at 5 ............................................................................................................................ ________
Set UEL KI at 3 ............................................................................................................................. ________
Set UEL Kg at 5 ............................................................................................................................ ________
Set var/PF KI at 3.......................................................................................................................... ________
Set var/PF Kg at 5......................................................................................................................... ________
PID Settings
On the Control Gain screen, click the tool bar PID button to open the PID window. (The Control Gain
screen Stability Range setting must be 21.) Use the PID window to select the correct PID values based
on generator time constant T’do and exciter time constant Te. For more information about PID settings,
refer to Section 5,
BESTCOMS Software, PID Window
.
The following suggested settings may be used for AVR and FCR modes when the generator and exciter
time constants are unknown.
Set KP at 80 .................................................................................................................................. ________
Set KI at 20 ................................................................................................................................... ________
Set KD at 15.................................................................................................................................. ________
Set AVR Kg at 7 ............................................................................................................................ ________
Set TD at 0.01 ............................................................................................................................... ________
Set FCR Kg at 400........................................................................................................................ ________
Verify transfer indications from the remote status indicators, front panel HMI or BESTCOMS
OFF-LINE TESTS - TURBINE SPINNING
For off-line tests with the turbine spinning, the generator circuit breaker is open.
FCR Mode
Initial testing should be conducted in FCR (manual) mode and minimum generated voltage.
Place the DECS-200 in FCR mode............................................................................................... ________
Place the Start/Stop switch in the Start position ........................................................................... ________
NOTE
If proper startup is not achieved, increase the value of loop gain (Kg) for AVR
and FCR modes.
