DECS-200 Installation 4-1
SECTION 4 • INSTALLATION
GENERAL
DECS-200 Digital Excitation Control Systems are delivered in sturdy cartons to prevent shipping damage.
Upon receipt of a system, check the part number against the requisition and packaging list for agreement.
Inspect for damage, and if there is evidence of such immediately file a claim with the carrier and notify the
Basler Electric Regional Sales Office, your sales representative or a sales representative at Basler
Electric, Highland, Illinois.
If the unit is not installed immediately, store it in the original shipping package in a moisture- and dust-free
environment.
PRODUCT REGISTRATION
Registering with Basler Electric enables you to receive important information updates on your product
plus new product announcements. Register your product by directing your web browser to
http://www.basler.com/Register
.
MOUNTING
The orientation of the DECS-200 heat sink requires vertical mounting for maximum cooling. Any other
mounting angle will reduce the DECS-200’s heat dissipation capability and possibly lead to premature
failure of critical components. The DECS-200 may be mounted anywhere that the ambient temperature
does not exceed the environmental conditions listed in Section 1,
General Information, Specifications
.
Overall DECS-200 dimensions are shown in Figure 4-1.
Two DECS-200 mounting configurations are possible: projection mounting and panel mounting. The
panel drilling diagram for projection mounting of a DECS-200 is shown in Figure 4-2. Panel mounting of a
DECS-200 is possible with the optional escutcheon plate (part number 9360107100). Escutcheon plate
dimensions are shown in Figure 4-3. The panel cutting and drilling diagram for the escutcheon plate is
illustrated in Figure 4-4.
CAUTION
The hardware provided with the escutcheon plate should be used to attach the
plate to the DECS-200. If other screws are used, ensure that the screw length is
no greater than ¼” (0.25”) and no less than 7/32” (0.219”).
