DECS-200 General Information 1-9
Off-Line Overexcitation Limiting
High Current Level
Pickup Range: 0 to 30.0 Adc
Pickup Increment: 0.1 Adc
Time Range: 0 to 10 s
Time Increment: 1 s
Low Current Level
Pickup Range: 0 to 30.0 Adc
Pickup Increment: 0.1 Adc
Time Range: 0 to 10 s
Time Increment: 1 s
Underexcitation Limiting
Adjustment Range: 0 to 100% of the generator rated apparent power (kvar) at 0 kW real
power. Or customizable to generator curve capability.
Manual Excitation Control
Range: 0 to 15.0 Adc
Increment: 0.1 Adc
Metering
Generator Voltage
Range: 0 to 160% of nominal
Accuracy: <1% (50/60 Hz)
Generator Current
Range: 0 to 200% of nominal
Accuracy: <1% (50/60 Hz)
Generator Frequency
Range: 10 to 90 Hz
Accuracy: ±0.1 Hz
Bus Voltage
Range: 0 to 160% of nominal
Accuracy: <1% (50/60 Hz)
Bus Frequency
Range: 10 to 90 Hz
Accuracy: ±0.1 Hz
Phase Angle
Range: –90 to +90
Accuracy: ±1.0
Field Voltage
Range: 0 to 375 Vdc
Accuracy: ±1.25 V or ±1.0% (whichever is greater)
Field Current
Range: 0 to 31 Adc
Accuracy: ±0.15 A or ±1.0% (whichever is greater)
Power Factor
Range: –0.5 to +0.5 PF
Accuracy: <0.02 PF
Real Power and Reactive Power
Range: 0 to 200% of nominal
Accuracy: <1.0% of nominal
