1-10 General Information DECS-200
Sequence of Event Recording (SER)
127 event report, stored in volatile memory (retrievable via BESTCOMS) SER triggered by: Input/Output
status changes, system operating status changes or alarm annunciations
Data Logging (Oscillograpy)
Stores 8 records in volatile memory. Up to 6 variables can be logged in a record. Sampling rate is 600
data points per log, up to 599 pre-trigger, 4 ms to 10 second intervals, (2.4 sec to 6,000 sec. total log
duration).
Temperature Range
Operating: –40 to +60°C (–40 to +140°F)
Storage: –40 to +85°C (–40 to +185°F)
CD-ROM: 0 to +50°C (32 to +122°F)
Type Tests
Shock
15 G in 3 perpendicular planes
Vibration
5 to 26 Hz: 1.2 G
27 to 52 Hz: 0.914 mm (0.036") double amplitude
53 to 500 Hz: 5 G
Surge Withstand Capability and Fast Transient
Tested per IEEE C37.90.1-1989
Dielectric Strength
Tested per IEEE 421.3
Salt Fog
Tested per MIL-STD-810E, Method 509.3
Physical
Weight: 6.35 kg (14 lb)
Dimensions: Refer to Section 4,
Installation
UL Recognition
UL recognized per standard 508, UL file number E90735.
CSA Certification
Certified per CSA Standard CAN/CSA-C22.2 Number 14, CSA File Number LR23131.
CE Compliance
The DECS-200 meets the criteria set forth by the following standards:
EN 50081-2
Electromagnetic compatibility (EMC) emissions standard: EN 55011, Level A.
EN 50082-2
Electromagnetic Compatibility (EMC) Immunity
Electrostatic Discharge (ESD)
EN 61000-4-2, Level B/IEC 1000-4-2
Radiated Susceptibility
EN 61000-4-3, Level A/IEC 1000-4-3
Electrical Fast Transient
EN 61000-4-4, Level B/IEC 1000-4-4
