1-6 General Information DECS-200
Contact Inputs
Type: Dry contact, accept PLC open-collector outputs
Interrogation Voltage: 12 Vdc
Terminal Assignments
Start: A21, A22
Stop: A23, A24
Auto (AVR): A25, A26
Manual (FCR): A27, A28
Raise: A29, A30
Lower: A31, A32
Pre-Position: A33, A34
Unit/Parallel (52L/M): A35, A36
Var/PF (52J/K): A37, A38
Secondary Enable: A39, A40
Alarm Reset: A41, A42
Contact Outputs
Make and Break Ratings
24 Vdc: 8.0 A
48 Vdc: 0.7 A
125 Vdc: 0.2 A
120/240 Vac: 10.0 A
Carry Ratings
24/48/125 Vdc: 8.0 A
120/240 Vac: 10.0 A
Terminal Assignments
Start/Stop (ON, OF): A11, A12
Watchdog (WTCHD): A13, A14
Relay 1 (RLY1): A15, A16
Relay 2 (RLY2): A17, A18
Relay 3 (RLY3): A19, A20
Field Output
Continuous Output Rating
60 Vac Input: 32 Vdc, 15 Adc
120 Vac Input: 63 Vdc, 15 Adc
240 Vac Input: 125 Vdc, 15 Adc
10 Second Forcing Output Rating
60 Vac Input: 50 Vdc, 30 Adc
120 Vac Input: 100 Vdc, 30 Adc
240 Vac Input: 200 Vdc, 30 Adc
Minimum Field Resistance
32 Vdc Application: 2.13 Ω
63 Vdc Application: 4.2 Ω
125 Vdc Application: 8.3 Ω
Regulation
AVR Operating Mode
Accuracy: ±0.25% over load range at rated PF and constant generator frequency
Steady State Stability: ±0.1% at constant load and generator frequency
Temperature Drift: ±0.5% for a 0 to 50°C change
V/Hz Characteristic: Slope from 0 to 3 PU is adjust-able in 0.1 PU increments. Voltage
regulation error is within ±2.0% of the nominal voltage.
Response Time: <1 cycle
