DECS-200 Functional Description 3-15
Oscillography
The data recording function of the DECS-200 can record up to eight oscillography records. Oscillography
records recorded by the DECS-200 use the IEEE Standard Common Format for Transient Data
Exchange (COMTRADE). Each record is time and date stamped. After eight records have been recorded,
the DECS-200 begins recording the next record over the oldest record. Because all oscillography records
are stored in volatile memory, the records will be lost if power is lost.
A record consists of six user selectable variables with 600 data points recorded for each variable. The
sample rate or time between data point samples is user selectable from 4 milliseconds to 10 seconds.
Therefore, the recording duration for a variable can range from 2.4 seconds to 6,000 seconds.
Data points may be selected for pre-trigger operation in order to capture events prior to a fault. Up to 599
pre-trigger data points may be selected. Data points that are not designated for pre-trigger recording are
assigned to the post-trigger portion of the fault record. This feature combined with the adjustable sample
rate allows for flexible data sampling around the fault.
The DECS-200 monitors six user-selectable internal variables. The following internal variables may be
selected:
Internal Variables
Auto tracking output (for future use)
Auxiliary input voltage
AVR Error Signal
Bus frequency
Bus voltage
Control output
Crosscurrent input
Exciter field current Ifd
Exciter field voltage Vfd
Generator average L-L voltage
Generator frequency
Generator Ib in amps
Generator kVA
Generator kvar
Generator kW
Generator power factor
Generator Vab
Generator Vbc
Generator Vca
Generator V-I phase angle
Internal PID Integrator State
Typically, these are used when commissioning or troubleshooting.
Data recording may be triggered manually using BESTCOMS, logic triggers, or level triggers.
Logic triggers allow data recording to occur as a result of an internal or external status change of the
DECS-200.
Level triggering allows the user to select triggering of a data record based on the value of one of the
internal variables. The value can be a minimum or maximum value and can be specified to trigger a
record when the monitored variable crosses a minimum threshold from above or a maximum threshold
from below. A minimum and maximum threshold may also be selected for the monitored variable causing
the monitored value to trigger a record when it goes above its maximum or falls below its minimum.
Figure 3-11 shows an example of a data record as it would look when viewed with BESTwave software.
The example illustrates a voltage step change while monitoring average voltage, field voltage, and field
current over a time period of 2.75 seconds.
For more information about selecting triggering types or levels, selecting internal variables for monitoring
or viewing oscillography records, see Section 5,
BESTCOMS Software
.
