DECS-200 Human-Machine Interface 2-25
EDM OD RIPL - open exciter diode ripple threshold
EDM SD RIPL - shorted exciter diode ripple threshold
Screen: \PROT\PROT_LEVL2 (5.5)
EDM INH LVL - exciter diode detection inhibit level
LOS BAL V - loss of balanced sensing voltage threshold
LOS IMBAL V - loss of unbalanced sensing voltage threshold
LOSS FIELD - loss of field time delay
Screen: \PROT\PROT_TIMER (5.6)
FIELD OV - field overvoltage time delay
FIELD OC TD - field overcurrent time dial multiplier
STATOR OV - generator output overvoltage time delay
STATOR UV - generator output undervoltage time delay
NO SENSING - lost sensing voltage time delay
EX DIOD OD - exciter open diode time delay
Screen: \PROT\PROT_TIMR2 (5.7)
EX DIOD SD - exciter shorted diode time delay
LOSS FIELD - loss of field time delay
Limiters
Screen: LIMITERS (6.0)
ENABLED - selects which limiters are enabled: NONE, UEL, OEL, OEL/UEL, SCL, SCL/UEL, SCL/OEL,
or SCL/OEL/UEL
Screen: \LIMIT\OPTION (6.1)
On-line overexcitation limiter style and options.
OEL STYLE - selects Summing Point or Takeover style overexcitation limiter
OEL OPTION - selects on-line and off-line overexcitation limiter control options:
Option 1 : On-line OEL settings are active when either the 52 J/K or 52 L/M contacts are open. Off-line
OEL settings are active when either the 52 J/K or 52 L/M contacts are closed.
Option 2 : On-line OEL settings are active when the 52 J/K contact is open. Off-line OEL settings are
active when the 52 J/K contact is closed.
Option 3 : On-line OEL settings are active at all times.
Screen: \LIMIT\ONLINE (6.2)
On-line overexcitation limiter (summing point) settings.
INST LIMIT - on-line overexcitation limiter instantaneous limit threshold
INST TIME - on-line overexcitation limiter instantaneous limit time delay
MED LIMIT - on-line overexcitation limiter medium current threshold
MED TIME - on-line overexcitation limiter medium current time delay
CONT LIMIT - on-line overexcitation limiter continuous (low) current threshold
Screen \LIMIT\OFFLINE (6.3)
Off-line overexcitation limiter (summing point) settings.
OEL HI LIM - off-line overexcitation limiter high current threshold
HI LIM TIME - off-line overexcitation limiter high current time delay
OEL LO LIM - off-line overexcitation limiter low current threshold
