Basler GigE SERIES User Manual

Standard Features AW00089317000
254 Basler ace GigE
Operating the Sequencer Using Basler pylon
You can use the pylon API to set the parameters for operating the sequencer in Free Selection
sequence advance mode from within your application software.
The following code snippet illustrates enabling and disabling the sequencer. The example assumes
that sequence sets were previously configured and are currently available in the camera’s memory.
// Enable the sequencer feature
Camera.SequenceEnable.SetValue( true );
// Disable the sequencer feature
Camera.SequenceEnable.SetValue( false );
You can also use the Basler pylon Viewer application to easily set the parameters.
Selecting Sequence Sets
Each sequence set is identified by a sequence set index number, starting from zero. The states of
the input line selects between the sequence sets by setting bit 0 of the sequence set address. The
address is simply the binary expression of the sequence set index number (see Table 39).
 If the input line is not set for invert, the high state of the input line will set bit 0 to 1 and the low
state will set bit 0 to 0.
 If the input line is set for invert, the low state of the input line will set bit 0 to 1 and the high state
will set bit 0 to 0.
A maximum of two sequence sets can be used.
Sequence Set Address Related Sequence Set
Bit 0
0 Sequence Set 0
1 Sequence Set 1
Table 39: Sequence Set Addresses and Related Sequence Sets (Input Line Not Set for Invert)

Basler GigE SERIES Specifications

General

Interface	GigE
Lens Mount	C-Mount, CS-Mount
Sensor	CMOS
Mount	C-mount, CS-mount
Power Supply	Power over Ethernet (PoE)
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	Varies by model
