Chapter 10 ALERTS AND ALARMS
10 - 4
10.3 ALARMS
10.3.1 Cal Sensors
Cause: The pump’s calibration data has been corrupted. Indicates a
malfunctioning digital PCB.
Audio response: single beep
LED response: none
Message duration: until <5089> code is entered
Issued if the pump detects, during the POST, that any of the four sensor functions has not
been calibrated.
The operator is allowed to enter Calibration Mode by pressing the key sequence 5,0,8,9,
but no other operation is allowed until all four sensor functions have been recalibrated.
Once the pump is in Calibration Mode, only the Y response is allowed at the CAL
DRIVEPOS, CAL SYRNGREC and CAL PRESSENS prompts.
10.3.2 Charge Depleted
Cause: battery voltage below minimum
Audio response: continuous beeps
LED response: ALERT LED flashes while message is displayed; BATTERY
LED on continuously
Message duration: until <5089> is entered or power is cycled
Issued following the POST if the pump detects that the battery voltage has fallen below 5.5
V at power up.
Any keypress will terminate the audio portion of the alarm. The pump will respond to all
keypresses with an error beep. The pump will allow the operator to access VB_SENSE
calibration directly by pressing 5,0,8,9.
10.3.3 Comm Fault
Cause: unrecoverable transmission error during configuration
replication
Audio response: continuous beeps
LED response: ALERT LED flashes while message is displayed
Message duration: until <5089> code is entered
Issued during configuration replication if the destination pump detects an unrecoverable
transmission error. The pump drops out of replication.
