Page #66 background image
ROUTINE MAINTENANCE Chapter 5
5 - 7
5.3.5 Calibration Procedure
5.3.5.1 Calibration Set-up
1. Plug the charger into a 115 VAC power source and connect the output connector of
the charger to the pump’s charger port.
2. Switch the pump “ON” and allow the pump to go through its power-on self-test (POST).
5.3.5.2 Activating Calibration Set Mode
NOTE
The pump sounds an error beep for each key pressed. These tones
are provided to discourage unauthorized access and may be ignored.
1. Enter access code 5089. The pump responds and DRIVEPOS appears on the
display. Disregard the numbers in the upper part of the display.
2. Press CONFIRM.
5.3.5.3 Plunger Driver Position Calibration Procedure
1. Observe the prompts, N and CAL DRIVEPOS, on the display.
2. Press the or key to change the flashing N to Y. Do not select N as this will
cause the pump to skip the Plunger Driver Position calibration sequence and continue
on to the Syringe Recognition Detection calibration sequence.
3. Press CONFIRM.
4. Calibrating the 2.798 Point
4.1 Observe the prompt, VERIFY 2.798, on the display.
4.2 Install the calibration fixture (CAS4001801) into the barrel clamp ensuring that the
flange of the fixture fits into the flange slot.
4.3 Push the barrel clamp in until the face contacts the fixture. Engage the plunger driver
onto the fixture.
NOTE
After installing the fixture, do not touch the plunger face or the fixture.
4.4 Press CONFIRM to lock in the 2.798 measurement.
5. Calibrating the 0.672 Point
