baxter Auto Syringe AS50 Service Manual

APPENDIX C REPAIR PARTS
C - 12
C.3 ALPHABETICAL PARTS LIST
Description Baxter® Part
Number
Figure
Number
Index
Number
Unit
Qty
.036 Stainless Steel Washer A100301429 F F-16 1
10-32 x 1/4" Pan Head Screw S103204613 F F-17 1
10-32 x 3/8" Hex Insert A100301439 F F-3 1
2-32 x 3/16" Black Pan Head Screw S023203663 C C-3 3
2-56 x 1/4" Pan Head Screw S025604652 F F-15 8
2-56 x 1/8" Socket Head Cap Screw S025602600 F F-14 2
2-56 x 11/16" Socket Head Cap Screw S025611600 D D-8 1
2-56 x 3/8" Socket Head Cap Screw S025606600 D D-7 2
2-56 x 9/16" Socket Head Cap Screw S025609600 E E-2 4
4-40 x 1/2" Flat Head Screw S044008614 D D-11 3
4-40 x 5/16" Flat Head Screw S044005614 D D-6 1
4-40 x 3/16" Button Head Screw S044003613 F F-5 2
4-40 Hex Nut N044002665 D D-10 1
Analog PCB Assembly DAS5001352 E E-8 1
Analog PCB Retainer DAS4001409 E E-7 1
AS50 Pump Caution Decal BAS5001010 D D-2 1
Barrel Clamp Assembly AAS5001503RP D D-1 1
Barrel Clamp Face CAS5001453 D D-4 1
Barrel Clamp Zebra Strip A100301249 D D-9 1
Battery Cover Assembly AAS5001473RP C C-2 1
Battery Stack Assembly AAS4001552RP C C-1 1
Battery Warning Decal BAS5001011 F F-2 1
Case/IV Pole Loop/Drive Assembly AAS5001531RP F F-1 1
Charger Assembly CAS4001900 H NA 1
Charger Port Decal BAS5001013 E E-12 1
Clamp Face Decal BAS5001009 D D-3 1
Conductive Gasket BAS4001486 E E-10 1
Connector Spacer BAS4001622 F F-10 1
Cover Screw BAS4001653 E E-4 1
Cover/Window Assembly AAS5001522RP E E-1 1
Digital PCB Retainer DAS4001408 E E-11 1
Digital/LCD PCB Assembly DAS5001353 E E-5 1
Electronic Chassis DAS4001410 E E-6 1
End Cap, Black Rubber DAS4005481 A A-1 2
End Cap, Blue Rubber DAS4002481 A A-1 2
End Cap, Gray Rubber DAS4001481 A A-1 2
End Cap, Green Rubber DAS4003481 A A-1 2
End Cap, Light Blue Rubber DAS4006481 A A-1 2
End Cap, Light Pink Rubber DAS4007481 A A-1 2
