baxter Auto Syringe AS50 Service Manual

ROUTINE MAINTENANCE Chapter 5
5 - 17
5.4 AS50 CALIBRATION DATA SHEET
Pump Serial Number: ________________________________________________________
PLUNGER DRIVER POSITION CALIBRATION
Proc. Step Specification Inches
Pass Fail
5.3.5.3 (7)
0.666 < inches < 0.678
5.3.5.3 (9)
2.792 < inches < 2.804
SYRINGE RECOGNITION DETECTION CALIBRATION
Proc. Step Specification Inches
Pass Fail
5.3.5.4 (13)
0.7367 < Inches < 0.7467
1st Reading
_________
2nd Reading
5.3.5.4 (15)
0.2859 < Inches < 0.2959
1st Reading
_________
2nd Reading
5.3.5.4 (17)
-0.03 < Inches < +0.02
1st Reading
_________
2nd Reading
5.3.5.4 (19)
0.995 < Inches < 1.035
1st Reading
_________
2nd Reading
PRESSURE SENSOR CALIBRATION
Proc. Step
Specification A/D Number
Pass Fail
5.3.5.5 (10.1)
145 < A/D Number < 175
5.3.5.5 (11.2)
-0.15 ≤ value ≤ +0.15
VB SENSE CALIBRATION
Proc. Step Specification Voltage
Pass Fail
5.3.5.7 (12)
6.090 ≤ Volta
g
e ≤ 6.110
5.3.5.7 (14)
7.490 ≤ Volta
g
e ≤ 7.510
5.3.5.7 (16)
5.490 ≤ Volta
g
e ≤ 5.510
Proc. Step
CALIBRATION CONFIRMATION
Pass Fail
5.3.5.7 (18)
Pum
p
p
asses all Calibrations.
Performed by: _____________________________ Date: _____________________
This page may be reproduced.
