DISASSEMBLY/ASSEMBLY PROCEDURES Chapter 7
7 - 1
7.1 GENERAL
This chapter contains a detailed description of the disassembly and assembly procedure
for the Auto Syringe® AS50 Infusion Pump. Contact Baxter Healthcare Corporation,
Andover Service Center if you have any questions while servicing the pump.
NOTES
When performing the procedures of this chapter, exercise extreme
caution during disassembly to protect the circuit boards from static
discharge. The inspection or repair station, all equipment, and
personnel are to be grounded.
During disassembly, note the orientation of all assemblies, assembly
parts, cables and connectors. Failure to do so may result in improper
operation and/or damage to the pump upon reassembly.
During disassembly, keep track of all hardware and ensure that all
parts are kept in a safe place. Avoid leaving loose hardware in the
pump upon reassembly. Failure to do so may result in improper
operation and/or electrical damage to the circuit boards.
Calibration must be performed after reassembly. Refer to Chapter 5
for the Calibration Procedure.
All pumps must pass the functional tests in Chapter 4 after repair is
complete.
WARNING
The pump may only be repaired by replacing the parts or sub-
assemblies listed in Appendix C. There are no user-repairable parts or
sub-assemblies. Service must be performed by a trained biomedical
engineering technician.
7.2 DISASSEMBLY PROCEDURES
Unless specified, the procedure to reassemble a component or an entire assembly is the
reverse of the disassembly procedure.
Numbers in parenthesis refer to the numbered parts of the drawing associated with the
procedure.
