TROUBLESHOOTING AND REPAIR Chapter 6
6 - 1
CHAPTER 6 - TROUBLESHOOTING AND REPAIR
6.1 GENERAL
Pumps under warranty must be returned to Baxter® for troubleshooting and repair.
Unauthorized disassembly/repair will void your warranty. When the pump is
malfunctioning, refer to the troubleshooting information in Table 6-1.
WARNING
There are no user-repairable parts or sub-assemblies. Service must
be performed by a trained biomedical engineering technician.
6.2 TROUBLESHOOTING
Table 6-1 contains troubleshooting tips. Note that repair to the pump may only consist of
the replacement of the parts or sub-assemblies listed in Appendix C. Refer to Chapter 7
for disassembly/assembly procedures and Appendix C for part information.
6.2.1 Tools and Equipment
• Large Phillips® screwdriver
• Small Phillips® screwdriver
• 5/64” Allen wrench
• Needle nose pliers
• 1/16” punch (or equivalent)
• Tweezers
• 89 ±0.1% ohm, 1 watt resistor
